COB Light 200w Chip

LED Type: COB (Chip on Board) High Power LED
Power Rating: 200W
Light Color: Cool White + Warm White (Dual Color)
Color Temperature: Cool White 6000K–6500K, Warm White 3000K–3500K
Working Voltage: DC 30V – 36V (per channel, model dependent)
Forward Current: 1500mA – 3000mA (recommended constant current driver)
Luminous Flux: Up to 18,000 – 22,000 Lumens
Beam Angle: 120° Wide Angle Illumination
CRI (Color Rendering Index): Ra ≥ 80
Connection Type: Wired solder terminals (+ / - connections)
Control Type: Independent White and Warm White channels for color mixing
Dimming Support: PWM and constant current dimming compatible
Mounting Type: Screw mount metal base for heatsink installation
Substrate Material: Ceramic insulated COB package with aluminum mounting base
Cooling System: Requires external aluminum heatsink and cooling fan for optimal performance
Heat Dissipation: High thermal conductivity design
Energy Efficiency: High brightness with low power consumption
Application: Photography Lights, Stage Lighting, Grow Lights, Outdoor Lighting Systems
Protection Class: IP20 (LED chip only – indoor use unless installed in a sealed housing)
Operating Temperature: -20°C to +60°C
Expected Lifespan: >50,000 Hours
Features: High brightness, stable performance, low heat resistance, long service life, dual-color illumination in a single LED module.
